Uploading Audio Files, KX-NS300BX

Transfers Outgoing Message (OGM) files from the PC to the Storage Memory Card. This option is only available at the Installer level when programming in On-line mode. Uploaded files are automatically renamed as necessary. If the location specified already contains an OGM, it will be overwritten by the newly uploaded message.

To transfer OGMs to the Storage Memory Card

1. From the Utility menu, select Message File Transfer PC to PBX.

2. Select the destination to transfer the OGM files to from the drop-down list, and then click Browse. The Open dialogue box will be displayed.

3. Select the message files to upload. The files must be in the WAV format. It is possible to select multiple files.

Note: When selecting files to copy to the PBX, the file names (apart from the file extension) cannot be more than 33 characters in length.

When selecting G.711 codec WAV files to copy to the PBX, the total file size of all selected files combined cannot exceed 32 megabytes.

4. Click OK.

The files will be uploaded. Files that do not contain message data will be ignored. An index number (01 to 64) will be appended automatically to the file names of message files transferred to the PBX. When complete, the display will return to the main screen.

Phones Management-Vega Telrad

This menu (Figure 4.56) allows you to get the list of registered VEGA VoIP clients (IP telephones, workstations + softphone) that where registered from the VEGA.I - Machines Management and to manage some configurations. By clicking on a phone name it’s possible to modify the following fields:

1). Phone: Phone username;

2). Password: Phone password that can be changed;

3). Alternative Phone Addresses: In that field we can have alternative addresses to the phone. An alternative address is another name (or number) to reach the telephone. This functionality is very useful when there are telephones from which you can only dial numbers. It’s a good policy to register phones by names and after that define a numeric alternative address.

4). Caller ID: If you want to mask the caller ID insert the full number;

5). Phone Location – Local: It’s the default, for a LAN phone; – Remote: For a remote phone that is connected behind a NAT. Usually this option is used when the idea is register the phone from the Internet, using the VEGA network public IP.

6). Auto provisioning: The auto provisioning option permits the automatic configuration of SIP hardphones, so here we just need to choose the phone model. To work, it’s mandatory when registering the phone at Machines Management, to insert the MAC address.

7). Description: This field should have a text description about the phone;

Machine Management-Telrad Vega

3.2 Machine Management This section deals with adding or changing machine registrations in LDAP (e.g. PC, laptop, printer). A machine is represented by the type, name, group, IP address and MAC address.

IP Phone: Hardware IP SIP phone in LAN. The name will be the SIP username and it will always be associated to the IP address;

Configuration Procedure of Adding IP Phone

Go to Vega.I, Select Machine Management

Click Insert,and configure all that apply (Note: Mcaddress will found at the buttom of IP Phone).

Updating IP Phone Firmware with POST MODE status

When you encounter the IP Phone in POST MODE status, this will require to update the firmware; to fix it, do the following;

1. Run Wftpd32 Software settings 2. Change firmware name to 1.z 3. Set the IP on your service laptop and then connect it to IP Phone 4. Power on the phone and long press # key to enter 5. Telnet Phone IP

Now follow the below procedure

1. Open Wftpd32 setup tool and click logging, log options, and tick all that apply except winsock calls

2. CLick security , user/rights

3. Enter User Name 123, and Password is also 123 click Ok,

4. Input the path where you put the update files

5. Configure your computer and set the IP address to

6. Connect cable in LAN port of phone to computer then power on the phone and long press the # key while power on the phone will enter POST MODE

7. open dos prompt (CMD)

8. Input telnet and press enter

9. Input Server Name: (This is your PC IP address)

10. Input image 1.z (This is your update files)

11. Input user name: 123 and password: 123 then enter, then will start the update, just wait until successfully completed.

Telrad Vega IP PABX System

The Vega 300 can be used with various combinations of telephony ports. It supports various technologies (PRI, BRI, Analog, SIP, IAX) with up to 1000 Users (SIP ext, Analog ext ports). The units are available in a standard 19” 2U rack/wall-mountable chassis.


User friendly Web Interface | Interface in Different Languages | CDR (Call Details Record) via Web access | TDM/SIP/IAX Trunks | Remote Extensions | Voicemail | Fax 2Mail | Mail2Fax | Unified Messaging | IVR Menu System | Ring Groups | Call Queues | Association of several alternative internal and external addresses | Video calls | DISA Features | FIREWALL | VPN (SSL, PPTP, IPSec, VNC, GRE | Proxy | Web Phone | web chat | IM (Instant Messaging Server) | Call center | Conference Rooms | URI based calls (dial by email address)| Follow-Me | Time-Based Routing | Advanced Dialing Rules | Music-On-Hold | Least Cost Routing | Web Access to Voicemail | Admin Status Screen | Package Manager (for easy updates) | Network Settings Tool | Phone Provisioning Tool | Echo Cancellation - OSLEC (Open Source Line Echo Cancelation).

  • Maximum number of concurrent calls 480
  • Maximum number of built-in analog ports32
  • (additional ports with external Unibox units)
  • Number of E1 / T1 ports 4 (up to 120 concurrent PRI calls)
  • Modules
  • 8 FXS ports
  • 8 FXO ports
  • Up to 8 BRI ISDN ports
  • Up to 12 modules of PRI (up to 45 concurrent calls}
  • Dimensions and Weight
  • Weight 8 Kg 18Lbs (weight depends on configuration)
  • Size 19'''' 2U industry standard rack-mountable chassis
